Mineral Processing High Chromium Cantilevered Slurry Pump

100% compatible and interchangeable inside liner slurry pump with expeller seal. Shaft seal can be gland packing seal or mechanical seal.
Interchangeable rubber and metal design makes it easy to install suitable material options for different applications.

Bearing assembly is cylindrical roller bearing which can adjust the space between impeller and front liner easily and can be removed completely when being repaired. Bearing  assembly use grease lubrication.

The discharge branch can be positioned at intervals of 45 degrees or oriented to any eight positions to suit installations and applications.

The drive method can be V belt drive, gear reducer drive, fluid coupling drive, or frequency conversion drive devices.

Capacity: 10.8 ~4000 m3/h

Head: 5~68m

Application:

· High density slurry transfer;

· Thickener underflow recirculation;

· Reagent dosing;

· Froth flotation;

· Cyanide processing etc.

· Mill discharge;

· Cyclone feed;

· Tailings
